Cost-Effectove USB2.0&HDMI 20X PTZ Video Camera

WINSAFE UHV-HU20-20 PTZ Video Camera with USB2.0 & HDMI interface, 20x optical zoom and high quality for your conference and online meeting.

item no.:
UHV-HU2-20
payment:
T/T
product origin:
China
color:
Black/White
shipping port:
Shenzhen
lead time：
3

contact now

Description
Information
Downloads

Product Advantages

* Crystal Image: with latest Advanced ISP, 1/2.8 inch SONY sensor and high quality 20x optical lens
* Fast and accurate focus performance
* Easy firmware upgrade-(field-upgradable)
* Compatible with almost video conferencing software(UVC1.5 protocol standard)
* Functional IR remote control
* Power via USB type C port

Product Features

* Zoom: 20X Optial Zoom & 4X Digital Zoom
* 60° degree field of view
* USB & HDMI simultaneously output, can set independent resolution
* HDMI output up to 1920x1080p60 Full HD
* Smart USB2.0 type C output, support multiple compress video format, max. output MJPG 1920X1080P60, adapt to different video application
* USB2.0 compatible with Windows, MAC OS, Android, Linux, Google Chrome and more
* Image flip function support upside-down installation
* Accurate pan tile motor control, ultra smooth PTZ movement
* Up to 128 presets
* Support RS232, RS485 serial control
* Standard Sony Visca and Pelco P/D protcol
* Support WDR, 3D-Noise Reduction function
* Adjustable lens parameters: Brightness, Contrast, Color, Resolution, Gama, AutoGain etc.
* Both ARM & ISP firmware can be easily upgraded via USB type C port

Model No.	UHV-HU2-20
Video Port	HDMI, USB2.0 Type-C
Video Resolution	HDMI: 1080P60/50/30/25; 720P60/50/30/25
Video Resolution	USB Type-C: MJPE: 19201080P60; 1280720P60; 1024576P60; 640480P60;640360P60 YUY2: 640480P30; 640360P30; 480640P30; 360*640P30
Image Sensor	1/2.8 inch high quality, 2.4MP CMOS Sony sensor
Zoom	20X optial zoom + 4X digital zoom
Field of Viewing	60°(wide) - 3.2°(tele)
Focal Length	f=3.92(near) - 47.32mm(far)
Iris	F1.5 -3.0
Pan Rotation Angle	-170° - +170°
Tilt Rotation Angle	-30° - +90°
Pan Rotation Speed	0° - 120°/s
Tilt Rotation Speed	0° - 80°/s
Preset	128 via Visca, 10 via IR remote
S/N Ratio	Above 50dB
Minimum Lux	0.01Lux
White Balance	Auto / Manual / Indoor / Outdoor / Sodium Lamps / Fluorescent Lampls
Focal Mode	Auto / Manual / Push
2D&3DNR	Supported
WDR	Supported
Anti-Flicker	50HZ/60HZ/OFF
Input Voltage	5V 1000mA(via USB type C) / DC12V 2A(via Power Adapter)
Dimension	220mm x 190mm x 173mm
Net Weight	1.25kg(2.8LB)
Accessory	Power adapter, Power cable, 3m USB Type-C cable, manual, warranty card
Color	Black/Silver/Grey/White
