item no.:
UHV-100-US2Feature
※ Ultra crystal video quality: with advanced DSP, 1/2.8" 2MP sensor and high quality 12MP lens
※ Plug & Play, avoid focal length setting
※ Flexible hinge design: fit for monitor/PC, tripod and on desk mount
※ All video,control and power over single USB2.0 cable
※ Works with Windows, Mac,Android, Linux OS
※ Standard UVC 1.5 protocol, compatible with most VC application
※ 12 megapixel optical lens, 4x digital zoom
※ 108 ° ultra wide field of viewing
※ 1920 x 1080p 30(MJPG) high definition
※ No motor design, zero mechanical failure risk
※ WDR, 3DNR, BLC,Anti-flicker feature
※ UVC control(via USB 2.0 port)
Specification
Model No. |
UHV-100-U2S |
Sensor |
1/2.8" inch high quality, 2.1MP Sony CMOS sensor |
Video System |
1080p30(MJPG), backward compatible |
Megapixel |
12MP Fixed lens |
Digital Zoom |
4X |
View Angle |
108° |
Sensor Resolution |
2.1 Megapixel |
Control Port |
USB2.0 |
Video Port |
USB2.0 |
Focal Length |
f=2.27mm |
S/N Rate |
More than 50dB |
Minimum Lux |
0.1 Lux |
White Balance |
Auto/Manual/Indoor/Outdoor |
Focus |
Fixed |
Iris |
F1.8 |
Electronic Shutter |
Auto |
Anti Flicker |
50Hz/60Hz/OFF |
BLC |
ON/OFF |
Input Voltage |
DC5V(USB3.0 port) |
Dimension(L x H x W) |
118.5mm x 88.5mm x 63.mm |
Net Weight |
0.3KG |
