item no.:
AMC-M1001V2payment:
T/Tproduct origin:
Chinacolor:
Black
Feature
※ Latest CMOS sensor, support up to 1080P30 video outputs
※ 10X optical zoom, up to 99 degree FOV
※ MJPEG/H.264 compression, standard UVC protocol
※ Tracking performance fits different size of shape of conference room
※ 1 audio input, 1 audio output
※ Power consumption is less than 5W
※ HDMI & USB video output interfaces
※ Advanced 2D/3D, great noise control performance
※ Controllable via USB interface or remote controller
※ Smooth and stable movement, precise positioning
※ Special cable entry design, easy for installation
Dimension
Specification
|
Model No. |
AMC-M1001V2 |
|
Camera |
|
|
Image Sensor |
1/2.8" CMOS, 2.16MP |
|
Resolution |
Max 1080p/30fps |
|
Focal |
f=5.15mm - 47.38mm |
|
IRIS |
F2.38 |
|
Optical Zoom |
10X |
|
Field of View |
62.6° - 7.08° |
|
Focus |
Auto , Manual, PTZ Trigger, One Push |
|
Min.illumination |
0.5Lux(Color), 0.1Lux(B/W) |
|
Shutter Speed |
1/1 - 1/10,000s |
|
AGC |
Auto/Manual |
|
White Balance |
Auto, One Push, Manual, Auto Track |
|
DNR |
2D/3D |
|
BLC |
Yes |
|
S/N Ratio |
Above 50dB |
|
Pan & Tilt |
|
|
Pan Range |
-90° - +90° |
|
Tilt Range |
-30° - +90° |
|
Pan Speed |
30°/s |
|
Tilt Speed |
20°/s |
|
Preset Number |
32 |
|
Interface |
|
|
Control |
RS-232 |
|
Video |
1 X HDMI |
|
Audio |
One line in, One Line out |
|
USB |
USB2.0, compatible with UVC1.0-1.5 |
|
IR Remote |
Yes |
|
General |
|
|
Power Consumption |
Below 5W |
|
Power Supply |
DC12V |
|
Working Temp |
0°C - +40°C |
|
Storage Temp |
-20°C - +60°C |
|
Dimension |
163mm x 101mm x 116+mm |
|
Weight |
0.6kg |
|
Color |
Black |
