item no.:
PATC-G1928/G2028/G40payment:
2product origin:
28Xcolor:
12Xshipping port:
IP67Feature
※ 384*288 high sensitive thermal imager, 19/25/40mm optional;
※ Integrated HAD 28X/36 visual zoom module, 550TVL;
※ Aluminum PTZ case with high strength, full weather proof;
※ IP index up to IP67, built-in surge and lighting strike protection device;
※ Built-in integrated defogging device, working temp range -45°C- +55°C;
※ 3 video outputs: thermal video, visual video and switch video;
※ Precise PTZ system with higher holding torque, PTZ positioning precision up to ±0.05°;
※ Protocol & baud rate self-adaptive, soft address supported;
※ Optional damping system for tough applications;
※ Digital image stabilization;
※ Image flip for stand / ceiling mount;
※ Video Freeze;
※ Wide Dynamic Range(WDR);
※ Day/Night(ICR);
※ 10.8 - 28V voltae output;
※ Auto power-off with low power supply.
Dimention
Model No. |
PATC-Z31936 |
PATC-Z34036 |
PATC-Z61936 |
PATC-Z64036 |
Thermal Imaging Camera |
||||
Sensor Type |
Uncooled Amorphns Silicon FPA |
|||
Resolution |
384 x 288 |
384 x 288 |
640 x 480 |
640 x480 |
Sensor Size |
17μm |
|||
Focal |
19mm |
40mm |
19mm |
40mm |
Focus |
Fixed |
|||
Image Frame Rate |
50HZ(PAL) / 60HZ(NTSC) |
|||
NETC(300K) |
60mK |
|||
FOV |
19.5° x 14.7° |
9.3° x 7° |
32° x 24.2° |
15.5° x 11.6° |
Detecting Range |
Vehicle :2570m; Man: 550m |
Vehicle: 5400m Man: 1170m |
Vehicle: 2570m Man: 550m |
Vehicle: 5400m Man: 1170m |
Recognition Range |
Vehicle: 640m Man: 130m |
Vehicle: 1350m Man: 290m |
Vehicle: 640m Man: 130m |
Vehicle: 1350m Man: 290m |
Digital Zoom |
1X, 2X, 4X |
|||
Daylight Imaging Camera |
||||
Video Sensor |
1/4" SONY EX-View HAD CCD |
|||
Effective Pixel |
PAL: 750(H) x 582(V); NTSC 768(H) x 494(V) |
|||
Resolution |
550TVL |
|||
Video System |
PAL/NTSC |
|||
Zoom |
Optical: 36X; Digital:12X |
|||
Lens |
f = 3.4mm - 122.4mm, F16.-F4.5 |
|||
View Angle |
57.8°(wide) - 1.8°(tele) |
|||
Min.Illumination |
Color: 1.4Lux; Mono:0.01Lux |
|||
WB |
Auto |
|||
Focus |
Auto/Manual |
|||
IRIS |
Auto/Manual |
|||
S/N Ratio |
Not less than 50dB |
|||
WDR |
Yes |
|||
BLC |
On/Off |
|||
Image Stabilization |
On/Off |
|||
DNR |
1 - 5 Step/Off |
|||
Day/Night |
Auto/Manual |
|||
PTZ |
||||
Pan Range |
360° Continuous |
|||
Pan Speed |
Control speed: 0.04° - 90°/s; Preset speed: 120°/s |
|||
Tilt Range |
-15° - 90°(Auto Flip) |
|||
Tilt Speed |
Control:0.3° - 60°/s, adjustable; Preset Speed: 90°/s |
|||
Preset |
256 |
|||
Preset Predicion |
±0.2° |
|||
General |
||||
Video Output |
1 Channel Thermal Imaging Video; 1 Channel Visual Video; 1 Channel Switch Video |
|||
Adress |
0 - 255 |
|||
Power Consumption |
35W/50W(Heater On) |
|||
Working Temperature |
-25°C - +65°C |
|||
Voltage |
DC24V |
|||
IP Code |
IP67 |
|||
Anti-Vibration |
Pan 9G, Tilt 15G |
|||
Wind Resistance |
180 Km/h |
|||
Dimensions |
Standard: Φ190(mm) x 275(mm); With Damper: Φ190(mm) x 300(mm) |
|||
Weight |
6kg W/O Damper; 7kg with Damper(Optional) |
