P2P 150M IR Distance IP High Speed Dome Camera

WINSAFE 150M Long IR Distance IP PTZ Camera, support P2O, 5MP Outdoor IP PTZ Camera are network cameras that can Pan, Tilt and Zoom to provide both wide-area coverage and great detail with a single camera, great image quality 2MP & 5MP optional.
  • item no.:

    WS-BT86
  • Description
  • Information
  • Downloads

Feature


  Support P2P function
  Laser+IR Max Distance is 150M
  Support 20/36X Optial Zoom,support full focus
  Support onvif,Best compatibility
  Compatible with DAHUA , HIKVISION , XM,UC2,AEVISION,Milestone
  Working Temperature -40℃+60℃
  Support RTSP and H.264/MJPEG Three steam encoding,support video output
  Dual system backup,fault self-recovery,support A-B, partol and other functions
  Support Transient voltage 6000V,Lightning Surge Protection
 PWM Auto Control IR LED,Brightness uniformity, low heat, infrared lamp life extension

Specification


Model No.

WS-BT86

DSP

HI3516C

HI3516D

HI3516D

Sensor

IMX323 2.0MP

AR0521 5.0MP

Panasonic34229 2.0MP

Resolution

HD:1080p/30fps1080p/25fps

2592*1944@15fps    2592*1944@22fps

1920*1080@25fps    1920*1080@30fps

Zoom

20X

20X

36X

Lens

f=4.7mm-94mm

f=4.7mm-94mm

f=4.6mm-165mm

Power

DC12V3A

Network Protocol

TCP/IP,HTTP,NTP,IGMP,DHCP,UDP,SMTP,RTP,RTSP,ARP,DDNS,DNS,HTTPS,P2P

Network Safe

HTTPS802.1XIP ADDRESS FILTERING

Pan rotation speed

300°/s

Tilt rotation speed

80°/s

Auto Control IR LED

PWM

Auto Flip

Horizontal 360°, Vertical 93°

A-B Scan

User programmable

Mechanical zero calibration

Support

Focal

 5.35mm~96.3mm/4.6 152mm/5.4mm-97mm

Video

H.264/H.265M-JPEG

Audio

 G711PCM

Mobile APP

AndroidIOS Hisee

Preset Points

220

Guard Tours

3 groups

Guard Points

Max.16 points, dwell time user selectable

Operating temperature

Indoor: 0°~ +40°             Outdoor: -40°~ +60°

Operation menu

English

Auto Control IR LED

PWM

IR distance

up to 150 meters

Software Control

IE, CMS, Management Platform

Power Consumption

15W

Lightning Protection

Transient voltage 6000V

Size

W330mm*D330mm*H520mm

Weight

N.W 1.65KG/G.W 2.38KG

Related validation

IP66,CE,FCC,RoHs
