Enabling a Safer Society and Smarter Living
item no.:
UHV-VA600-4Kproduct origin:
Chinacolor:
Blacklead time：
5Video Part
• Adopted advanced high definition DSP, 1/2.5” 8.5MP CMOS sensor and high quality fixed 4K lens with 120 degree FOV, to provide sharp and crystal clear image.
• 4x electronic zoom adjustable.
• An ultra-wide, big depth of field fixed lens is used.
• AI feature: auto framing to output best video experience
• USB2.0 type C port output high and low video resolution for different application scalable
• Max resolution 2160p60 (MJPG/H.264) is supported.
• Support standard UVC1.0~1.5 protocol, working with any your favorite video conferencing software. API is supported.
• Matched with RF remote control to set video and audio.
• Support Chinese and English OSD menu
Audio Part
• Uses Microphone Array Algorithms
By sampling and processing the spatial characteristics of sound field, the background sound can be removed to the maximum extent, leaving only the needed sound waves, even in the noisy environment , it can make the voice sound clear without noise;
• High Definition Audio
16K pickup and 24K playback, to make voice crystal clear, sounding like face-to-face meeting.360° Omni-directional pickup, the pickup range is up to 5 meters and voice quality is
most ideal in 3 meters.
• Outstanding Full Duplex Communication
Freely and fluent two-ways communication in 5 meters.
• Advanced Speech Algorithms
360° Omni-directional and long distance pick
Full duplex communication
384ms acoustic echo cancellation
Background noise suppression
Auto-level loud and soft voices
Peak-limiting algorithm eliminates even momentary speaker clipping to prevent distortion
|
Model No. |
UHV-VA600-4K |
|
Video |
|
|
Sensor |
1/2.5" CMOS sensor |
|
Effective Pixel |
8.5M effective pixels 16:9 |
|
Scan |
Progressive |
|
Lens |
f=2.22mm±5% |
|
Iris |
F=2.4±5% |
|
FOV |
120° |
|
Focus Mode |
Fixed |
|
White Balance |
ATW/Auto/Manual/Outdoor/Indoor/Sodium/Fluorescent/Onepush |
|
Iris |
Auto/Manual/Brightness Priority/Shutter Priority |
|
Anti-Flicker |
OFF/50Hz/60Hz |
|
Noise-Flicker |
2D & 3D |
|
Wide Dynamic |
Support |
|
Backlight compensation |
Support |
|
Color Enhancement |
Support |
|
Edge Enhancement |
Support |
|
Image Flip |
Support |
|
Image Mirroring |
Support |
|
Electronic Pan/Tilt |
Support |
|
Auto Frame |
Support |
|
Remote controller |
2.4G remote controller to set OSD menu, audio, mute, video |
|
USB Port |
USB2.0 Type C |
|
Protocol |
UVC1.0-1.5 |
|
Video Format |
MIJPG/H.264/YUY2 |
|
Resolution |
MJPG/H.264 |
|
Audio |
|
|
Audio Input/ Output |
Built-in Omni-directional microphone array |
|
Protocol |
UAC |
|
Microphone |
4pcs Omni-directional microphone |
|
Speaker |
4Ω/8W 100-24KHz 2 inch anti-magnetic horn |
|
Pickup bandwidth |
100-16KHz |
|
Sampling frequency |
32KHz(Ascending), 48KHz(Descending) |
|
Sensitivity |
- 38dB - 94dB SPL@1KHz |
|
S/N ratio |
65dB 94dB SPL@1KHz |
|
Audio Feature |
Auto acoustic echo cancellation, Auto gain, Auto background noise suppression, Full-duplex, 360°Omni-directional pickup, Array Microphone algorithms |
|
Pickup range |
3~5meters, ideal within 3 meters |
|
Others |
|
|
Operation System |
Windows7/8/10, MAC OS 10.7 and above, Android, Linux |
|
Power Consumption |
12V/500Ma, power adapter |
|
PoE |
Supported(IEEE802.af) |
|
Dimension |
395mm x 113mm x 112mm |
|
Work Temperature |
0°~40°C |
|
Storage Temperature |
-40°~70°C |
|
Color |
Metal Silver, White, Black. |
